This model is concerned about design and modeling of PTC/CST solar thermal power for power generation. Reverse osmosis and main grid are considerd the load on the turbine unit. MED/MSF desalination plants will act as a condensation/desalination part through the cycle. The thermal power via solar PTC and CST will be transferred through the boiler heat exchanger unit to power on thermal steam Rankine cycle (power). The plant consists of the following:
1-Solar Molten Salt PTC and or CST.
2-Boiler heat exchanger unit with two storage sections (hot & cold).
3-Pump (Molten Salt).
4-Turbine unit.
5-MSF or MEDpf desalination.
6-Pump (steam).
7-Reverse Osmosis plant.
8-Cost block.
9-Performance block.**Watch the tutorial videos:
Part I: https://www.youtube.com/watch?v=NGwtCVOa3SY
Part II: https://www.youtube.com/watch?v=kZrywHn8wys
**MatLab-SimuLink should be used to run the model.
